康納溫菲爾德公司發布Stratum3E標準的14腳OCXO振蕩器

來源：金洛鑫瀏覽：- 發布日期：2024-01-02 08:59:19【大中小】

分享到：

康納溫菲爾德公司發布Stratum3E標準的14腳OCXO振蕩器，伊利諾伊州奧羅拉，ConnorWinfield晶振公司新推出的OH414針DIP系列OCXO是基于SC切割晶體的振蕩器專門設計用于與<1mH至.1Hz的低濾波器帶寬配合使用，以符合基于T1的層次結構規范，例如ITU-TG.8262選項1和2ECC、ITU-TG.8263、ITU-TG.813選項1和2SEC，用于Sonet、IEEE1588和同步以太網的第3層和3E層。CW的OH4OCXO系列采用小尺寸14x20mm作為SMD或14引腳DIP通孔封裝。

OH4OCXO振蕩器系列配置選項提供10ppb峰峰值頻率穩定性、-40至+85C的工業溫度范圍以及出色的性能，低相位噪聲、短期穩定性和老化特性。

康納溫菲爾德公司發布Stratum3E標準的14腳OCXO振蕩器

特征：

•可用頻率范圍從10MHz到100MHz，標準頻率為12.8MHz，19.2MHz、19.44MHz、20MHz、24.576MHz、25MHz、38.88MHz、40MHz和100MHz。
•3.3VLVCMOS或正弦輸出
•固定輸出或電壓控制
•符合在.1Hz帶寬下測量的層級MTIE和TDEV掩模
•10ppb峰峰值溫度穩定性
•在12kHz-20MHz頻段內低于300ps的抖動性能
•使用壽命精度為+/-1ppm
•完全符合ROHS和REACH標準

•14x20mm貼片或通孔封裝選項

原廠代碼	品牌	型號	類型	頻率	輸出	電壓	穩定度	工作溫度
DGOF5S3-020.0M	Connor-Winfield	DGOF	OCXO	20MHz	HCMOS, TTL	5V	250ppb	0°C ~ 70°C
DGOF5S3-010.0M	Connor-Winfield	DGOF	OCXO	10MHz	HCMOS, TTL	5V	250ppb	0°C ~ 70°C
DOCSC022F-025.0M	Connor-Winfield	DOCSC	OCXO	25MHz	LVCMOS	3.3V	±20ppb	-40°C ~ 85°C
DOCSC022F-025.0M	Connor-Winfield	DOCSC	OCXO	25MHz	LVCMOS	3.3V	±20ppb	-40°C ~ 85°C
DOCSC022F-025.0M	Connor-Winfield	DOCSC	OCXO	25MHz	LVCMOS	3.3V	±20ppb	-40°C ~ 85°C
OH4610LF-040.0M	Connor-Winfield	OH4	OCXO	40MHz	LVCMOS	3.3V	±10ppb	-40°C ~ 85°C
OH4610LF-025.0M	Connor-Winfield	OH4	OCXO	25MHz	LVCMOS	3.3V	±10ppb	-40°C ~ 85°C
OH100-61003CF-010.0M	Connor-Winfield	OH100	OCXO	10MHz	CMOS	3.3V	±10ppb	-40°C ~ 85°C
OH300-61003CF-010.0M	Connor-Winfield	OH300	OCXO	10MHz	CMOS	3.3V	±10ppb	-40°C ~ 85°C
OH300-61003CF-010.0M	Connor-Winfield	OH300	OCXO	10MHz	CMOS	3.3V	±10ppb	-40°C ~ 85°C
OH300-61003CF-010.0M	Connor-Winfield	OH300	OCXO	10MHz	CMOS	3.3V	±10ppb	-40°C ~ 85°C
BSOF3S3E-010.0M	Connor-Winfield	BSOF3S3E	OCXO	10MHz	HCMOS	3.3V	±10ppb	0°C ~ 70°C
ASOF3S3-020.0M	Connor-Winfield	ASOF3S3	OCXO	20MHz	LVCMOS	3.3V	250ppb	0°C ~ 70°C
ASOF3S3-012.8M	Connor-Winfield	ASOF3S3	OCXO	12.8MHz	LVCMOS	3.3V	250ppb	0°C ~ 70°C
OH100-50503CF-010.0M	Connor-Winfield	OH100	OCXO	10MHz	CMOS	3.3V	±5ppb	0°C ~ 70°C
OH100-50503CF-012.8M	Connor-Winfield	OH100	OCXO	12.8MHz	CMOS	3.3V	±5ppb	0°C ~ 70°C
OH100-61003CF-020.0M	Connor-Winfield	OH100	OCXO	20MHz	CMOS	3.3V	±10ppb	-40°C ~ 85°C
ASOF3S3-010.0M	Connor-Winfield	ASOF3S3	OCXO	10MHz	LVCMOS	3.3V	250ppb	0°C ~ 70°C
OH100-61003CF-012.8M	Connor-Winfield	OH100	OCXO	12.8MHz	CMOS	3.3V	±10ppb	-40°C ~ 85°C
OX400-620LF-020.0M	Connor-Winfield	OX400-620LF	OCXO	20MHz	LVCMOS	3.3V	±20ppb	-40°C ~ 85°C
OX400-620LF-024.576M	Connor-Winfield	OX400-620LF	OCXO	24.576MHz	LVCMOS	3.3V	±20ppb	-40°C ~ 85°C
OH4610LF-38.88M	Connor-Winfield	OH4	OCXO	38.88MHz	LVCMOS	3.3V	±10ppb	-40°C ~ 85°C
OH100-70503CF-024.576M	Connor-Winfield	OH100	OCXO	24.576MHz	CMOS	3.3V	±5ppb	-20°C ~ 70°C
OH100-70503CF-020.0M	Connor-Winfield	OH100	OCXO	20MHz	CMOS	3.3V	±5ppb	-20°C ~ 70°C
OH300-70503CF-020.0M	Connor-Winfield	OH300	OCXO	20MHz	CMOS	3.3V	±5ppb	-20°C ~ 70°C
OH300-70503CF-020.0M	Connor-Winfield	OH300	OCXO	20MHz	CMOS	3.3V	±5ppb	-20°C ~ 70°C
OH300-70503CF-020.0M	Connor-Winfield	OH300	OCXO	20MHz	CMOS	3.3V	±5ppb	-20°C ~ 70°C
OHSM100-60803CF-010.0M	Connor-Winfield	OHSM100-60803CF	OCXO	10MHz	LVCMOS	3.3V	±8ppm	-40°C ~ 85°C
OH200-61003CF-024.576M	Connor-Winfield	OH200	OCXO	24.576MHz	CMOS	3.3V	±5ppb	-40°C ~ 85°C
OH100-60503CF-024.576M	Connor-Winfield	OH100	OCXO	24.576MHz	CMOS	3.3V	±5ppb	-40°C ~ 85°C
OH200-61003CF-020.0M	Connor-Winfield	OH200	OCXO	20MHz	CMOS	3.3V	±5ppb	-40°C ~ 85°C
DOCSC022F-024.576M	Connor-Winfield	DOCSC	OCXO	24.576MHz	LVCMOS	3.3V	±20ppb	-40°C ~ 85°C
DOCSC022F-024.576M	Connor-Winfield	DOCSC	OCXO	24.576MHz	LVCMOS	3.3V	±20ppb	-40°C ~ 85°C
DOCSC022F-024.576M	Connor-Winfield	DOCSC	OCXO	24.576MHz	LVCMOS	3.3V	±20ppb	-40°C ~ 85°C
OH200-51003CF-012.8M	Connor-Winfield	OH200	OCXO	12.8MHz	CMOS	3.3V	±5ppb	0°C ~ 70°C
OH200-51003CF-005.0M	Connor-Winfield	OH200	OCXO	5MHz	CMOS	3.3V	±5ppb	0°C ~ 70°C
OH100-50503CF-020.0M	Connor-Winfield	OH100	OCXO	20MHz	CMOS	3.3V	±5ppb	0°C ~ 70°C
OH300-61003CF-012.8M	Connor-Winfield	OH300	OCXO	12.8MHz	CMOS	3.3V	±10ppb	-40°C ~ 85°C
OH300-61003CF-012.8M	Connor-Winfield	OH300	OCXO	12.8MHz	CMOS	3.3V	±10ppb	-40°C ~ 85°C
OH300-61003CF-012.8M	Connor-Winfield	OH300	OCXO	12.8MHz	CMOS	3.3V	±10ppb	-40°C ~ 85°C
OH300-50503CF-020.0M	Connor-Winfield	OH300	OCXO	20MHz	CMOS	3.3V	±5ppb	0°C ~ 70°C
OH300-50503CF-020.0M	Connor-Winfield	OH300	OCXO	20MHz	CMOS	3.3V	±5ppb	0°C ~ 70°C
OH300-50503CF-020.0M	Connor-Winfield	OH300	OCXO	20MHz	CMOS	3.3V	±5ppb	0°C ~ 70°C
OH300-70503CF-024.576M	Connor-Winfield	OH300	OCXO	24.576MHz	CMOS	3.3V	±5ppb	-20°C ~ 70°C
OH300-70503CF-024.576M	Connor-Winfield	OH300	OCXO	24.576MHz	CMOS	3.3V	±5ppb	-20°C ~ 70°C
OH300-70503CF-024.576M	Connor-Winfield	OH300	OCXO	24.576MHz	CMOS	3.3V	±5ppb	-20°C ~ 70°C
OH300-50503CF-012.8M	Connor-Winfield	OH300	OCXO	12.8MHz	CMOS	3.3V	±5ppb	0°C ~ 70°C
OH300-50503CF-012.8M	Connor-Winfield	OH300	OCXO	12.8MHz	CMOS	3.3V	±5ppb	0°C ~ 70°C
OH300-50503CF-012.8M	Connor-Winfield	OH300	OCXO	12.8MHz	CMOS	3.3V	±5ppb	0°C ~ 70°C
OH300-60503CF-024.576M	Connor-Winfield	OH300	OCXO	24.576MHz	CMOS	3.3V	±5ppb	-40°C ~ 85°C
OH300-60503CF-024.576M	Connor-Winfield	OH300	OCXO	24.576MHz	CMOS	3.3V	±5ppb	-40°C ~ 85°C
OH300-60503CF-024.576M	Connor-Winfield	OH300	OCXO	24.576MHz	CMOS	3.3V	±5ppb	-40°C ~ 85°C
OH300-61003CF-020.0M	Connor-Winfield	OH300	OCXO	20MHz	CMOS	3.3V	±10ppb	-40°C ~ 85°C
OH300-61003CF-020.0M	Connor-Winfield	OH300	OCXO	20MHz	CMOS	3.3V	±10ppb	-40°C ~ 85°C
OH300-61003CF-020.0M	Connor-Winfield	OH300	OCXO	20MHz	CMOS	3.3V	±10ppb	-40°C ~ 85°C
OH300-50503CF-010.0M	Connor-Winfield	OH300	OCXO	10MHz	CMOS	3.3V	±5ppb	0°C ~ 70°C
OH300-50503CF-010.0M	Connor-Winfield	OH300	OCXO	10MHz	CMOS	3.3V	±5ppb	0°C ~ 70°C
OH300-50503CF-010.0M	Connor-Winfield	OH300	OCXO	10MHz	CMOS	3.3V	±5ppb	0°C ~ 70°C
OH300-61003CF-040.0M	Connor-Winfield	OH300	OCXO	40MHz	CMOS	3.3V	±10ppb	-20°C ~ 70°C
OH300-61003CF-040.0M	Connor-Winfield	OH300	OCXO	40MHz	CMOS	3.3V	±10ppb	-20°C ~ 70°C
OH300-61003CF-040.0M	Connor-Winfield	OH300	OCXO	40MHz	CMOS	3.3V	±10ppb	-20°C ~ 70°C
OHSM100-60803CF-020.0M	Connor-Winfield	OHSM100-60803CF	OCXO	20MHz	LVCMOS	3.3V	±8ppm	-40°C ~ 85°C
DOCSC022F-040.0M	Connor-Winfield	DOCSC	OCXO	40MHz	LVCMOS	3.3V	±20ppb	-40°C ~ 85°C
DOCSC022F-040.0M	Connor-Winfield	DOCSC	OCXO	40MHz	LVCMOS	3.3V	±20ppb	-40°C ~ 85°C
DOCSC022F-040.0M	Connor-Winfield	DOCSC	OCXO	40MHz	LVCMOS	3.3V	±20ppb	-40°C ~ 85°C
OH4610LF-024.576M	Connor-Winfield	OH4	OCXO	24.576MHz	LVCMOS	3.3V	±10ppb	-40°C ~ 85°C
DOCSC022F-020.0M	Connor-Winfield	DOCSC	OCXO	20MHz	LVCMOS	3.3V	±20ppb	-40°C ~ 85°C
DOCSC022F-020.0M	Connor-Winfield	DOCSC	OCXO	20MHz	LVCMOS	3.3V	±20ppb	-40°C ~ 85°C
DOCSC022F-020.0M	Connor-Winfield	DOCSC	OCXO	20MHz	LVCMOS	3.3V	±20ppb	-40°C ~ 85°C
OH4610LF-012.8M	Connor-Winfield	OH4	OCXO	12.8MHz	LVCMOS	3.3V	±10ppb	-40°C ~ 85°C
OH4610LF-010.0M	Connor-Winfield	OH4	OCXO	10MHz	LVCMOS	3.3V	±10ppb	-40°C ~ 85°C
OH4610LF-020.0M	Connor-Winfield	OH4	OCXO	20MHz	LVCMOS	3.3V	±10ppb	-40°C ~ 85°C
ASOF5S3-012.8M	Connor-Winfield	ASOF5S3	OCXO	12.8MHz	HCMOS	5V	250ppb	0°C ~ 70°C
ASOF5S3-019.44M	Connor-Winfield	ASOF5S3	OCXO	19.44MHz	HCMOS	5V	250ppb	0°C ~ 70°C
OH200-51003CF-010.0M	Connor-Winfield	OH200	OCXO	10MHz	CMOS	3.3V	±5ppb	0°C ~ 70°C
OFC5DJ3BS-010.0M	Connor-Winfield	OFC5DJ3BS	OCXO	10MHz	Sine Wave	5V	±20ppb	-20°C ~ 70°C
OFC5DJ3BS-020.0M	Connor-Winfield	OFC5DJ3BS	OCXO	20MHz	Sine Wave	5V	±20ppb	-20°C ~ 70°C
DOCSC012F-020.0M	Connor-Winfield	DOCSC	OCXO	20MHz	LVCMOS	3.3V	±10ppb	-40°C ~ 85°C
OH300-50503CF-025.0M	Connor-Winfield	OH300	OCXO	25MHz	CMOS	3.3V	±5ppb	0°C ~ 70°C
OH300-50503CF-025.0M	Connor-Winfield	OH300	OCXO	25MHz	CMOS	3.3V	±5ppb	0°C ~ 70°C
OH300-50503CF-025.0M	Connor-Winfield	OH300	OCXO	25MHz	CMOS	3.3V	±5ppb	0°C ~ 70°C
OH300-50503CF-040.0M	Connor-Winfield	OH300	OCXO	40MHz	CMOS	3.3V	±5ppb	0°C ~ 70°C
OH300-50503CF-040.0M	Connor-Winfield	OH300	OCXO	40MHz	CMOS	3.3V	±5ppb	0°C ~ 70°C
OH300-50503CF-040.0M	Connor-Winfield	OH300	OCXO	40MHz	CMOS	3.3V	±5ppb	0°C ~ 70°C
OH300-61003CF-025.0M	Connor-Winfield	OH300	OCXO	25MHz	CMOS	3.3V	±10ppb	-40°C ~ 85°C
OH300-61003CF-025.0M	Connor-Winfield	OH300	OCXO	25MHz	CMOS	3.3V	±10ppb	-40°C ~ 85°C
OH300-61003CF-025.0M	Connor-Winfield	OH300	OCXO	25MHz	CMOS	3.3V	±10ppb	-40°C ~ 85°C
DOCSC012F-040.0M	Connor-Winfield	DOCSC	OCXO	40MHz	LVCMOS	3.3V	±10ppb	-40°C ~ 85°C
OH300-50503CF-050.0M	Connor-Winfield	OH300	OCXO	50MHz	CMOS	3.3V	±5ppb	0°C ~ 70°C
OH300-50503CF-050.0M	Connor-Winfield	OH300	OCXO	50MHz	CMOS	3.3V	±5ppb	0°C ~ 70°C
OH300-50503CF-050.0M	Connor-Winfield	OH300	OCXO	50MHz	CMOS	3.3V	±5ppb	0°C ~ 70°C
OH300-61003CF-050.0M	Connor-Winfield	OH300	OCXO	50MHz	CMOS	3.3V	±10ppb	-40°C ~ 85°C
OH300-61003CF-050.0M	Connor-Winfield	OH300	OCXO	50MHz	CMOS	3.3V	±10ppb	-40°C ~ 85°C
OH300-61003CF-050.0M	Connor-Winfield	OH300	OCXO	50MHz	CMOS	3.3V	±10ppb	-40°C ~ 85°C
