LORA模塊低抖動專用晶振530FC125M000DG/125MHz/XO/7050mm/2.5V/SMD-6
Silicon晶振Si530 XO利用天空工作解決方案的先進DSPLL®電路提供一個高頻低抖動時鐘。Si530可提供從10到945MHz的任意速率輸出頻率，并選擇頻率到1400MHz。與傳統的XO不同，每個輸出頻率都需要一個不同的晶體，石英晶體振蕩器Si530使用一個固定的晶體來提供一個大范圍的輸出頻率。這種基于集成電路的方法允許晶體諧振器提供特殊的頻率穩定性和可靠性。此外，DSPLL時鐘合成提供了優越的電源噪聲抑制，簡化了在通信系統中通常發現的噪聲環境中產生低抖動時鐘的任務。有源晶振Si530 IC的XO可在工廠中進行配置，可用于各種用戶規格，包括頻率、電源電壓、輸出格式和溫度穩定性。特定的配置在裝運時被工廠編程，從而消除了與定制振蕩器相關的長交貨時間。LORA模塊低抖動專用晶振530FC125M000DG/125MHz/XO/7050mm/2.5V/SMD-6
| 原廠代碼 | 貼片晶振廠家 | 型號 | 頻率 | 電壓 | 頻率穩定度 | 包裝/封裝 |
| 530FB125M000DG | Silicon晶振 | Si530 | 125MHz | 2.5V | ±20ppm | 6-SMD, No Lead |
| 530BB125M000DG | Silicon晶振 | Si530 | 125MHz | 3.3V | ±20ppm | 6-SMD, No Lead |
| 530FB200M000DG | Silicon晶振 | Si530 | 200MHz | 2.5V | ±20ppm | 6-SMD, No Lead |
| 530BC156M250DG | Silicon晶振 | Si530 | 156.25MHz | 3.3V | ±7ppm | 6-SMD, No Lead |
| 530BA125M000DG | Silicon晶振 | Si530 | 125MHz | 3.3V | ±50ppm | 6-SMD, No Lead |
| 530BB100M000DG | Silicon晶振 | Si530 | 100MHz | 3.3V | ±20ppm | 6-SMD, No Lead |
| 530FC156M250DG | Silicon晶振 | Si530 | 156.25MHz | 2.5V | ±7ppm | 6-SMD, No Lead |
| 530FA156M250DG | Silicon晶振 | Si530 | 156.25MHz | 2.5V | ±50ppm | 6-SMD, No Lead |
| 530FC125M000DG | Silicon晶振 | Si530 | 125MHz | 2.5V | ±7ppm | 6-SMD, No Lead |
| 530AC622M080DG | Silicon晶振 | Si530 | 622.08MHz | 3.3V | ±7ppm | 6-SMD, No Lead |
| 530AC125M000DG | Silicon晶振 | Si530 | 125MHz | 3.3V | ±7ppm | 6-SMD, No Lead |
| 530AC200M000DG | Silicon晶振 | Si530 | 200MHz | 3.3V | ±7ppm | 6-SMD, No Lead |
| 530BC200M000DG | Silicon晶振 | Si530 | 200MHz | 3.3V | ±7ppm | 6-SMD, No Lead |
| 530FC200M000DG | Silicon晶振 | Si530 | 200MHz | 2.5V | ±7ppm | 6-SMD, No Lead |
| 530AC156M250DG | Silicon晶振 | Si530 | 156.25MHz | 3.3V | ±7ppm | 6-SMD, No Lead |
| 530AC155M520DG | Silicon晶振 | Si530 | 155.52MHz | 3.3V | ±7ppm | 6-SMD, No Lead |
| 530BC148M500DG | Silicon晶振 | Si530 | 148.5MHz | 3.3V | ±7ppm | 6-SMD, No Lead |
| 530AC106M250DG | Silicon晶振 | Si530 | 106.25MHz | 3.3V | ±7ppm | 6-SMD, No Lead |
| 530EC106M250DG | Silicon晶振 | Si530 | 106.25MHz | 2.5V | ±7ppm | 6-SMD, No Lead |
| 530FC106M250DG | Silicon晶振 | Si530 | 106.25MHz | 2.5V | ±7ppm | 6-SMD, No Lead |
| 530BC106M250DG | Silicon晶振 | Si530 | 106.25MHz | 3.3V | ±7ppm | 6-SMD, No Lead |
| 530EC155M520DG | Silicon晶振 | Si530 | 155.52MHz | 2.5V | ±7ppm | 6-SMD, No Lead |
| 530EC187M500DG | Silicon晶振 | Si530 | 187.5MHz | 2.5V | ±7ppm | 6-SMD, No Lead |
| 530AC000110DG | Silicon晶振 | Si530 | 148.35165MHz | 3.3V | ±7ppm | 6-SMD, No Lead |
| 530AC148M500DG | Silicon晶振 | Si530 | 148.5MHz | 3.3V | ±7ppm | 6-SMD, No Lead |
| 530EC000110DG | Silicon晶振 | Si530 | 148.35165MHz | 2.5V | ±7ppm | 6-SMD, No Lead |
| 530FC000110DG | Silicon晶振 | Si530 | 148.35165MHz | 2.5V | ±7ppm | 6-SMD, No Lead |
| 530BC155M520DG | Silicon晶振 | Si530 | 155.52MHz | 3.3V | ±7ppm | 6-SMD, No Lead |
| 530EC156M250DG | 貼片晶振 | Si530 | 156.25MHz | 2.5V | ±7ppm | 6-SMD, No Lead |
| 530AC187M500DG | Silicon晶振 | Si530 | 187.5MHz | 3.3V | ±7ppm | 6-SMD, No Lead |
| 530BC187M500DG | Silicon晶振 | Si530 | 187.5MHz | 3.3V | ±7ppm | 6-SMD, No Lead |
| 530FC187M500DG | Silicon晶振 | Si530 | 187.5MHz | 2.5V | ±7ppm | 6-SMD, No Lead |
| 530EC148M500DG | Silicon晶振 | Si530 | 148.5MHz | 2.5V | ±7ppm | 6-SMD, No Lead |
| 530EC200M000DG | Silicon晶振 | Si530 | 200MHz | 2.5V | ±7ppm | 6-SMD, No Lead |
| 530FC155M520DG | Silicon晶振 | Si530 | 155.52MHz | 2.5V | ±7ppm | 6-SMD, No Lead |
| 530BC000110DG | Silicon晶振 | Si530 | 148.35165MHz | 3.3V | ±7ppm | 6-SMD, No Lead |
| 530FC148M500DG | Silicon晶振 | Si530 | 148.5MHz | 2.5V | ±7ppm | 6-SMD, No Lead |
| 530EC312M500DG | Silicon晶振 | Si530 | 312.5MHz | 2.5V | ±7ppm | 6-SMD, No Lead |
| 530BC250M000DG | Silicon晶振 | Si530 | 250MHz | 3.3V | ±7ppm | 6-SMD, No Lead |
| 530EC311M040DG | Silicon晶振 | Si530 | 311.04MHz | 2.5V | ±7ppm | 6-SMD, No Lead |
| 530FC311M040DG | Silicon晶振 | Si530 | 311.04MHz | 2.5V | ±7ppm | 6-SMD, No Lead |
| 530FC622M080DG | Silicon晶振 | Si530 | 622.08MHz | 2.5V | ±7ppm | 6-SMD, No Lead |
| 530BC311M040DG | Silicon晶振 | Si530 | 311.04MHz | 3.3V | ±7ppm | 6-SMD, No Lead |
| 530EC622M080DG | Silicon晶振 | Si530 | 622.08MHz | 2.5V | ±7ppm | 6-SMD, No Lead |
| 530BC622M080DG | Silicon晶振 | Si530 | 622.08MHz | 3.3V | ±7ppm | 6-SMD, No Lead |
| 530AC311M040DG | Silicon晶振 | Si530 | 311.04MHz | 3.3V | ±7ppm | 6-SMD, No Lead |
| 530FC312M500DG | Silicon晶振 | Si530 | 312.5MHz | 2.5V | ±7ppm | 6-SMD, No Lead |
| 530AC312M500DG | Silicon晶振 | Si530 | 312.5MHz | 3.3V | ±7ppm | 6-SMD, No Lead |
| 530EC250M000DG | Silicon晶振 | Si530 | 250MHz | 2.5V | ±7ppm | 6-SMD, No Lead |
| 530AC250M000DG | Silicon晶振 | Si530 | 250MHz | 3.3V | ±7ppm | 6-SMD, No Lead |
| 530FC250M000DG | Silicon晶振 | Si530 | 250MHz | 2.5V | ±7ppm | 6-SMD, No Lead |
| 530BC312M500DG | Silicon晶振 | Si530 | 312.5MHz | 3.3V | ±7ppm | 6-SMD, No Lead |
| 530FC50M0000DG | Silicon晶振 | Si530 | 50MHz | 2.5V | ±7ppm | 6-SMD, No Lead |
| 530AA156M250DG | Silicon晶振 | Si530 | 156.25MHz | 3.3V | ±50ppm | 6-SMD, No Lead |
| 530FB100M000DG | Silicon晶振 | Si530 | 100MHz | 2.5V | ±20ppm | 6-SMD, No Lead |
| 530BC125M000DG | Silicon晶振 | Si530 | 125MHz | 3.3V | ±7ppm | 6-SMD, No Lead |
| 530EC125M000DG | Silicon晶振 | Si530 | 125MHz | 2.5V | ±7ppm | 6-SMD, No Lead |
| 530CA28M6000DG | Silicon晶振 | Si530 | 28.6MHz | 3.3V | ±50ppm | 6-SMD, No Lead |
| 530AC125M000DGR | Silicon晶振 | Si530 | 125MHz | 3.3V | ±7ppm | 6-SMD, No Lead |
| 530BC125M000DGR | Silicon晶振 | Si530 | 125MHz | 3.3V | ±7ppm | 6-SMD, No Lead |
| 530EC125M000DGR | Silicon晶振 | Si530 | 125MHz | 2.5V | ±7ppm | 6-SMD, No Lead |
| 530AC106M250DGR | Silicon晶振 | Si530 | 106.25MHz | 3.3V | ±7ppm | 6-SMD, No Lead |
| 530BC106M250DGR | Silicon晶振 | Si530 | 106.25MHz | 3.3V | ±7ppm | 6-SMD, No Lead |
| 530EC106M250DGR | Silicon晶振 | Si530 | 106.25MHz | 2.5V | ±7ppm | 6-SMD, No Lead |
| 530FC106M250DGR | Silicon晶振 | Si530 | 106.25MHz | 2.5V | ±7ppm | 6-SMD, No Lead |
| 530BC25M0000DGR | Silicon晶振 | Si530 | 25MHz | 3.3V | ±7ppm | 6-SMD, No Lead |
| 530RB150M000DG | Silicon晶振 | Si530 | 150MHz | 2.5V | ±20ppm | 6-SMD, No Lead |
| 530RB200M000DG | Silicon晶振 | Si530 | 200MHz | 2.5V | ±20ppm | 6-SMD, No Lead |
| 530BC100M000DG | Silicon晶振 | Si530 | 100MHz | 3.3V | ±20ppm | 6-SMD, No Lead |
| 530AC155M520DGR | Silicon晶振 | Si530 | 155.52MHz | 3.3V | ±7ppm | 6-SMD, No Lead |
| 530AC156M250DGR | Silicon晶振 | Si530 | 156.25MHz | 3.3V | ±7ppm | 6-SMD, No Lead |
| 530BC155M520DGR | Silicon晶振 | Si530 | 155.52MHz | 3.3V | ±7ppm | 6-SMD, No Lead |
| 530BC156M250DGR | Silicon晶振 | Si530 | 156.25MHz | 3.3V | ±7ppm | 6-SMD, No Lead |
| 530EC155M520DGR | Silicon晶振 | Si530 | 155.52MHz | 2.5V | ±7ppm | 6-SMD, No Lead |
| 530EC156M250DGR | Silicon晶振 | Si530 | 156.25MHz | 2.5V | ±7ppm | 6-SMD, No Lead |
| 530FC155M520DGR | Silicon晶振 | Si530 | 155.52MHz | 2.5V | ±7ppm | 6-SMD, No Lead |
| 530FC156M250DGR | Silicon晶振 | Si530 | 156.25MHz | 2.5V | ±7ppm | 6-SMD, No Lead |
| 530AC187M500DGR | Silicon晶振 | Si530 | 187.5MHz | 3.3V | ±7ppm | 6-SMD, No Lead |
| 530BC187M500DGR | Silicon晶振 | Si530 | 187.5MHz | 3.3V | ±7ppm | 6-SMD, No Lead |
| 530EC187M500DGR | Silicon晶振 | Si530 | 187.5MHz | 2.5V | ±7ppm | 6-SMD, No Lead |
| 530FC187M500DGR | Silicon晶振 | Si530 | 187.5MHz | 2.5V | ±7ppm | 6-SMD, No Lead |
| 530AC000110DGR | 進口晶振 | Si530 | 148.35165MHz | 3.3V | ±7ppm | 6-SMD, No Lead |
| 530AC148M500DGR | Silicon晶振 | Si530 | 148.5MHz | 3.3V | ±7ppm | 6-SMD, No Lead |
| 530AC200M000DGR | Silicon晶振 | Si530 | 200MHz | 3.3V | ±7ppm | 6-SMD, No Lead |
| 530BC000110DGR | Silicon晶振 | Si530 | 148.35165MHz | 3.3V | ±7ppm | 6-SMD, No Lead |
| 530BC148M500DGR | Silicon晶振 | Si530 | 148.5MHz | 3.3V | ±7ppm | 6-SMD, No Lead |
| 530BC200M000DGR | Silicon晶振 | Si530 | 200MHz | 3.3V | ±7ppm | 6-SMD, No Lead |
| 530EC000110DGR | Silicon晶振 | Si530 | 148.35165MHz | 2.5V | ±7ppm | 6-SMD, No Lead |
| 530EC148M500DGR | Silicon晶振 | Si530 | 148.5MHz | 2.5V | ±7ppm | 6-SMD, No Lead |
| 530EC200M000DGR | Silicon晶振 | Si530 | 200MHz | 2.5V | ±7ppm | 6-SMD, No Lead |
| 530FC000110DGR | Silicon晶振 | Si530 | 148.35165MHz | 2.5V | ±7ppm | 6-SMD, No Lead |
| 530FC148M500DGR | Silicon晶振 | Si530 | 148.5MHz | 2.5V | ±7ppm | 6-SMD, No Lead |
| 530BC130M250DG | Silicon晶振 | Si530 | 130.25MHz | 3.3V | ±7ppm | 6-SMD, No Lead |
| 530BC154M000DG | Silicon晶振 | Si530 | 154MHz | 3.3V | ±7ppm | 6-SMD, No Lead |
| 530AC312M500DGR | Silicon晶振 | Si530 | 312.5MHz | 3.3V | ±7ppm | 6-SMD, No Lead |
| 530BC312M500DGR | Silicon晶振 | Si530 | 312.5MHz | 3.3V | ±7ppm | 6-SMD, No Lead |
| 530EC312M500DGR | Silicon晶振 | Si530 | 312.5MHz | 2.5V | ±7ppm | 6-SMD, No Lead |
| 530FC312M500DGR | Silicon晶振 | Si530 | 312.5MHz | 2.5V | ±7ppm | 6-SMD, No Lead |
| 530AC250M000DGR | Silicon晶振 | Si530 | 250MHz | 3.3V | ±7ppm | 6-SMD, No Lead |
| 530AC311M040DGR | Silicon晶振 | Si530 | 311.04MHz | 3.3V | ±7ppm | 6-SMD, No Lead |
| 530AC622M080DGR | Silicon晶振 | Si530 | 622.08MHz | 3.3V | ±7ppm | 6-SMD, No Lead |
| 530BC250M000DGR | Silicon晶振 | Si530 | 250MHz | 3.3V | ±7ppm | 6-SMD, No Lead |
| 530BC311M040DGR | Silicon晶振 | Si530 | 311.04MHz | 3.3V | ±7ppm | 6-SMD, No Lead |
| 530BC622M080DGR | Silicon晶振 | Si530 | 622.08MHz | 3.3V | ±7ppm | 6-SMD, No Lead |
| 530EC250M000DGR | Silicon晶振 | Si530 | 250MHz | 2.5V | ±7ppm | 6-SMD, No Lead |
| 530EC311M040DGR | Silicon晶振 | Si530 | 311.04MHz | 2.5V | ±7ppm | 6-SMD, No Lead |
| 530EC622M080DGR | Silicon晶振 | Si530 | 622.08MHz | 2.5V | ±7ppm | 6-SMD, No Lead |
| 530FC250M000DGR | Silicon晶振 | Si530 | 250MHz | 2.5V | ±7ppm | 6-SMD, No Lead |
| 530FC311M040DGR | Silicon晶振 | Si530 | 311.04MHz | 2.5V | ±7ppm | 6-SMD, No Lead |
| 530FC622M080DGR | Silicon晶振 | Si530 | 622.08MHz | 2.5V | ±7ppm | 6-SMD, No Lead |
| 530CA40M0000BG | Silicon晶振 | Si530 | 40MHz | 3.3V | ±50ppm | 6-SMD, No Lead |
Si530晶振特點：
可與任意速率輸出頻率從10MHz到945MHz和選擇頻率1.4GHz
第三代DSPLL®具有優越的抖動性能
比基于saw的振蕩器好3倍的頻率穩定性
內部固定晶體頻率確保高可靠性和低老化
可用CMOS，LVPECL，LVDS，和CML輸出差分晶振
3.3V，2.5V，和1.8V供應選項
工業標準7.0x5.0mm毫米包和針形
無鉛/RoHS兼容
應用于：超聲波SONET/SDH，網絡，SD/高清視頻，測試和測量，時鐘和數據恢復，FPGA/ASIC時鐘生成
